ER collet ER 11
- 308881
- Version
- Through hardened and ground.
Corrosion protection: Collets fully coated with FAHRION Protect, including the functional faces.
- Advantage
- The coating increases the service life of the collet and ensures full functionality and precision.
- Note
- The collet clamping ⌀ range is always up to 1 mm less than nominal, e.g. ⌀ 10 − 9 mm, except for ⌀ 1, 1.5 and 2 (where it is only 0.5 mm).
Specifications
- Adapter
- ER 11
- Standard
- ISO 15488-B
- Concentricity
- ≤ 5
- Type
- 4008 E
- External ⌀ D
- 11.3 mm
- Overall length L
- 18 mm
- Type of product
- Collet
Execution and specifications
| Show details | Article no. | Nominal clamping ⌀ d | Gross CHF | Qty. | Actions |
|---|---|---|---|---|---|
589633 | 1 mm | 33.73 | per Piece | ||
589634 | 1.5 mm | 33.73 | per Piece | ||
589635 | 2 mm | 33.73 | per Piece | ||
589636 | 2.5 mm | 33.73 | per Piece | ||
589637 | 3 mm | 27.40 | per Piece | ||
589638 | 3.5 mm | 27.40 | per Piece | ||
589639 | 4 mm | 27.40 | per Piece | ||
589640 | 4.5 mm | 27.40 | per Piece | ||
589641 | 5 mm | 27.40 | per Piece | ||
589642 | 5.5 mm | 27.40 | per Piece | ||
589643 | 6 mm | 27.40 | per Piece | ||
589644 | 6.5 mm | 27.40 | per Piece | ||
589645 | 7 mm | 27.40 | per Piece |
