RUD Lifting points Load bracket Thread VLBG-PLUS
- 3881
- Advantage
- - Attachment point can be rotated 360°. Suspension bracket can be swivelled up to 180°
- Optimised load-bearing capacity thanks to captive but replaceable ICE-BOLT or captive but replaceable RUD screw; with special Corrud-DT 10.9 corrosion protection
- Much higher load-bearing capacity than eyebolts to DIN 580
- All load-bearing parts crack-tested or test-loaded in accordance with EN 1677
- With screwable RUD anchor points, the screws are also 100% crack-tested
- 4-fold safety in every load direction
- Adjust type VRS, VRM and VLBG in load direction
- Low construction heights, dynamic and static strengths
- Technical Data
- T=Total height when mounted
C=Internal width
Complies with Machinery Directive 98/37/CE
- Application Area
- VLBG-PLUS metric, high-strength
- Application Notes
- For correct and secure suspension of all types of devices and machines
Specifications
- Material
- Steel
Execution and specifications
| Show details | Article no. | M | WLL | T | C | Gross CHF | Qty. | Actions |
|---|---|---|---|---|---|---|---|---|
729964 | M8 | 630 kg | 75 mm | 34 mm | 95.13 | per Piece | ||
540902 | M10 | 900 kg | 75 mm | 34 mm | 92.97 | per Piece | ||
540901 | M12 | 1350 kg | 75 mm | 34 mm | 95.13 | per Piece | ||
584275 | M16 | 2000 kg | 85 mm | 38 mm | 101.61 | per Piece | ||
651400 | M20 | 3500 kg | 110 mm | 54 mm | 115.67 | per Piece | ||
579730 | M24 | 4500 kg | 125 mm | 54 mm | 124.32 | per Piece | ||
540894 | M30 | 6700 kg | 147 mm | 65 mm | 225.93 | per Piece | ||
740968 | M36 | 8000 kg | 146 mm | 82 mm | 443.21 | per Piece | ||
636425 | M42 | 15000 kg | 196 mm | 82 mm | 572.93 | per Piece | ||
636426 | M48 | 12000 kg | 222 mm | 100 mm | 626.98 | per Piece |
