LED luminaire Surf Line Mini R81
- 66753
- Description
- Surface-mounted luminaire with extremely flat rectangular aluminium housing
Opal cover, silver-coloured end caps
Note
If the luminaire is recessed, item 712673 or 712685 must also be ordered.
Functions: ON, OFF (dimming possible)
Assembly density R81
Connection cable 200mm
- Advantage
- Can be shortened by yourself (note 25mm repeat)
Specifications
- Material
- Aluminium
- Shielding angle
- 120 °
- System
- Surf Line
- Typ
- Luminaire
- Voltage
- 12 V
- Power per metre
- 9.4 W
- Light colour
- 2700+3000 Kelvin
- Widt
- 10 mm
- Height
- 5 mm
- LED placement [LED/m]
- 120
Execution and specifications
- Surface
| Show details | Article no. | Power | Kelvin | Surface | Length | Gross CHF | Qty. | Actions |
|---|---|---|---|---|---|---|---|---|
2101505 | 13.9 W | 2700 K | colourless anodized | 1500 mm | 65.40 | per Piece | ||
2101504 | 13.9 W | 2700 K | colourless anodized | 1500 mm | 65.40 | per Piece | ||
2101503 | 23.5 W | 2700 K | colourless anodized | 2500 mm | 105.40 | per Piece | ||
2101502 | 23.5 W | 2700 K | colourless anodized | 2500 mm | 105.40 | per Piece | ||
2101509 | 13.9 W | 2700 K | black | 1500 mm | 76.21 | per Piece | ||
2101508 | 13.9 W | 2700 K | black | 1500 mm | 76.21 | per Piece | ||
2101507 | 23.5 W | 2700 K | black | 2500 mm | 130.26 | per Piece | ||
2101506 | 23.5 W | 2700 K | black | 2500 mm | 130.26 | per Piece | ||
2089710 | 13.9 W | 3000 K | colourless anodized | 1500 mm | 62.05 | per Piece | ||
2089709 | 13.9 W | 3000 K | colourless anodized | 1500 mm | 62.05 | per Piece | ||
2089707 | 23.5 W | 3000 K | colourless anodized | 2500 mm | 99.99 | per Piece | ||
2089667 | 23.5 W | 3000 K | colourless anodized | 2500 mm | 99.99 | per Piece | ||
2090028 | 13.9 W | 3000 K | black | 1500 mm | 73.08 | per Piece | ||
2090027 | 13.9 W | 3000 K | black | 1500 mm | 73.08 | per Piece | ||
2089708 | 23.5 W | 3000 K | black | 2500 mm | 124.86 | per Piece | ||
2090029 | 23.5 W | 3000 K | black | 2500 mm | 124.86 | per Piece |
